Finger Clip Pulse Oximeter Display Four Color OLED SpO2 Measurement Range 70%-100%
Product Details:
| Place of Origin: | China |
| Brand Name: | THXC |
| Certification: | CE |
| Model Number: | TX-2-OM3 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pieces |
|---|---|
| Price: | $5.28-7.15/ piece |
| Packaging Details: | carton |
| Delivery Time: | 7-15 |
| Payment Terms: | L/C, D/A, T/T, D/P, Western Union, MoneyGram |
| Supply Ability: | 50000 pieces/per Month |
|
Detail Information |
|||
| Product Name: | Finger Clip Pulse Oximeter | Power Source: | 2*1.5V (2 AAA Batteries) |
|---|---|---|---|
| Display Specifications:: | Four Color OLED | Material: | ABS+PC |
| SpO2 Measurement Range: | 70%-100%(resolition:1%) | PR Range: | 30~240 Bpm |
| High Light: | 240bpm Finger Clip Pulse Oximeter,TX-2-OM3,2 AAA Clip Pulse Oximeter |
||
Product Description
Finger Clip Pulse Oximeter Display Four Color OLED SpO2 Measurement Range 70%-100%
Product Specifications
| Product Name | Finger Clip Pulse Oximeter |
| Product Size | 64*39*37mm |
| Color | Blue and white |
| SpO2 Measurement range | 70%-100% |
| Pulse cate range | 30 bpm-240 bpm |
| Weight | 43g |
| Power Supply | 2*1.5V 2*AAA |
Introduction:
From medical analysis, blood oxygen content (%SpO2) is greater than or equal to 95, which is a normal index; Pulse rate (/min) between 60 and 100 is a normal indicator. If the values you have detected do not meet the above two indicators, please monitor 2-3 times at different time points to maintain continuous monitoring for 2-3 days, if the values still do not meet the standard values, it is recommended that you go to the hospital for detailed treatment.
The principle of finger oximeter is based on the absorption spectrum characteristics of reduced hemoglobin and oxygenated hemoglobin in red light and near-red light regions, and uses Lambert Beer's law to establish an empirical formula for data processing. The working principle of finger oximeter adopts photoelectric blood oxygen detection technology combined with volumetric pulse imaging technology, with two beams of light of different wavelengths (660nm red light and 940nm near-infrared light) through the perspective finger sensor illuminated the tip of the human nail and the photosensitive element to obtain the measurement signal, the obtained information is processed by electronic circuits and microprocessors by two sets of LEDs to display the measured results.
FAQ
Q1:Can I have a sample for testing?
A:Yes, we can provide most samples for free, but you need pay for the express cost.
Q2:Can I add my logo on the medical products?
A:Yes,OEM and ODM are available for us.But you should send us the Trademark authorization letter.
Q3:How can I get the after-service?
A: We will be responsible for our products in the valid time.
Q4:Do you have inspection procedures for medical products?
A:100% self-inspection before packing ,We have QC and QA team.
